Oil is the lifeblood of machinery, analysis can help detect a developing problem in the oil-wetted path of a machine.

The "Quick Sample Status" of the report gives you a concise overview of whether the conditions detected fall into the realm of contamination, oil condition or abnormal wear

This is a list of standard tests that come with your Wear Check USA oil analysis kits that Kleenoil USA

To properly evaluate machine conditions, the oil samples submitted for analysis must be representative of the system from which they are taken.

NOTE: When taking oil samples from hydraulic systems for particle count analysis, special care must be taken to assure the samples are representative and that they are contamination free.

The sample information form allows the laboratory to match the current sample with historical data from that piece of equipment.

The form also contains information such as miles on oil, which aids the laboratory in providing the oil analysis user with proper evaluation of test data

The cleanliness of your hydraulic fluid is critical to the trouble free and cost effective operation of your system. Hydraulic components are very expensive and need special consideration when selecting and filtering this fluid.

ISO 4406 (International Standards Organization) code is a standard that is recognized in the industry. Certain recommended fluid cleanliness quantities are necessary to realize the best performance and cost saving operation of your hydraulic system.

This chart clearly demonstrates the effectiveness of the Kleenoil Filter System by showing the number of times that the life of engine and hydraulic components can be extended. The area highlighted on the chart in yellow shows the number of times that the life of a component would be extended when going from brand new oil right out of the barrel to oil that has been filtered using one of the Kleenoil Bypass Filtration Systems.

The ISO 4406 cleanliness level standard is used to reference the number of particles greater than 5 and greater than 15 microns in a known volume. For our usage, this volume will be 1 ml. The number of 5+ micron particles is used as a reference point for “silt” particles. The 5 - 15 size range indicates the quantity of larger particles present, which contribute greatly to potential catastrophic component failure. Now, the way the ISO chart lists the “ISO Code” is with a two number system. For example, the approximate rating of new oil off the store shelf would be rated at 18/15.
